Schering Bridge (ME 2201E)
On Board six unknown capacitor are mounted behind the front panel with connections are brought out on front panel.
Product Overview
On Board six unknown capacitor are mounted behind the front panel with connections are brought out on front panel.
Used To calculate the value of capacitor (0.01mF - 1mF).
In built fixed DC regulated power supply of ±5V ±12V & +5V/
500mA.
Inbuilt sine wave oscillator, frequency 1KHz ±3%, amplitude 0-
15Vpp.
In built 3½ digit digital null detector used as detector.
On Board two ratio dial “P” & “Q” each having 10 W,100W &
1000W
On Board two decade dial x (0.01 mF & 0.01mF).
For more details please refer datasheet.
Technical Specifications
Used To calculate the value of capacitor (0.01mF - 1mF).
In built fixed DC regulated power supply of ±5V ±12V & +5V/
500mA.
Inbuilt sine wave oscillator, frequency 1KHz ±3%, amplitude 0-
15Vpp.
In built 3½ digit digital null detector used as detector.
On Board two ratio dial “P” & “Q” each having 10 W,100W &
1000W
On Board two decade dial x (0.01 mF & 0.01mF).
For more details please refer datasheet.
